Maintenance and attention of vibro sifter
Vibro sifter maintenance
– Jan 01, 2019-
Vibro sifter maintenance
(1)working on the stable and flat ground
(2) before start up the machine check on the parts completely
(3) after 100 hours operations, check on all the nuts, bolts and other parts completely
(4) prohibit starting up the machine without the screener
(5) starting up the machine with extro-charge is not allowed
(6) not allowed to adjust any thing when operating
(7) loosen the wrench (5#), 1-2 parts can be easy to dismantle
(8) when the checking cover is unfolded, it can be very easy to check on the vibration parts
(9) please do not change the vibrator optionally
(10) if there is something wrong about the electric current, check on the circle program.
(11) Add the grease (lithium lube grease) every 500 hours.
(12) Adjuster parts:
Adjustment of swing range of vibro sifter machine
In order to change the swing range of vibro sifter, it is needed to dismantle the screener net and the pedestal. Generally the range descending can obtain the best swing.
The phasic angles of the two blocks to the swing range as follows:
|
Rotation angle |
0° |
45° |
60° |
90° |
|
Swing range |
4mm |
3mm |
2mm |
1mm |
Attention: fold the upper cover well, screw the collet tight and then start up the machine.
SOP on Preventive maintenance of Vibro Sifter
1.0 Objective:
To lay down a procedure for Preventive Maintenance of Vibro sifter.
2.0 Scope:
This SOP is applicable for the preventive maintenance of Vibro sifter to pharmaceutical formulation plant.
3.0 Responsibility:
3.1 Technician/above –Engg. Is responsible for Preventive Maintenance of Vibro sifter
4.0 Accountability:
4.1 Head- Engg. Shall be accountable for implementation and compliance of this SOP
5.0 Abbreviation
Not Applicable
6.0 Procedure:
6.1 Monthly:
6.1.1 Before carried out the preventive maintenance Switch off the incoming supply and display UNDER PREVENTIVE MAINTENANCE.
6.1.2 Check rugged spring for proper tight ness, rectify if any abnormality.
6.1.3 Check dead weight for proper fitting.
6.1.4 Lubricate the motor bearings.
6.1.5 Check wheels for free movement and it should lock proper if any abnormalities rectify it.
6.1.6 Check motor electrical terminals for proper tightness.
6.1.7 Check all gaskets for any damage, replace if required.
6.1.8 Check operation sifter for proper vibration if less vibration adjust the dead weight.
6.1.9 Record the details in attached annexure no.-I
7.0 List of Annexure / Format
7.1 Check list for Preventive maintenance of Vibro Sifter – I
8.0 References
8.1 SOP on SOPs.
8.2 Operating manual
9.0 History
Date |
Revision Number |
Reason for revision |
– |
00 |
New SOP |
Annexure-I
Preventive Maintenance Record of Vibro sifter.
| ID No. OF Equipment: | |
| Capacity: | |
| Area: | |
| Frequency: Monthly. | |
Date:
| Sr.
No. |
CHECK POINTS | STATUS |
| 01 | Check rugged spring for proper tightness, rectify if any abnormality. | |
| 02
|
Check dead weight for proper fitting. |
|
| 03 | Lubricate the motor bearings. |
|
| 04 | Check wheels for free movement and it should lock proper if any abnormalities rectify it. |
|
| 05 | Check motor electrical terminals for proper tightness. | |
| 06 | Check all gaskets for any damage, replace if required. | |
| 07 | Check operation sifter for proper vibration if less vibration adjust the dead weight. |
Done By: Checked By
